◆技巧性能指標 Main technical parameters (請往前手機瀏覽多大量例圖片視頻以此為準資料)
工具規格 Model |
STR-9070/9080 |
STR-1010 |
運作艙尺寸大小 Internal size(mm) |
900×800×650 |
1000×1000×790 |
整個機器長寬高 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
開關電源 Power |
220V 50Hz |
220V 50Hz |
絲機光照燈 Machine floodlight |
一壺60W防暴燈 |
220V 13W工業節能燈管 |
滾簡承擔 Roller bearing |
10-30Kg |
10-30Kg |
分開器電機的 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
剝離器風速 Separator air volume |
8.5m3/min |
8.5m3/min |
減小水汽源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
機子體積 Weight |
320kg |
380 kg |
◆設備特別 Product features
1. 的設計別出心裁、美觀度畢節、空間結構生物學、實際操作簡便;
2. 電腦自動的保持電腦自動的噴砂,應有按時噴砂,點動wifi定位等功能模塊;
3. 滾簡外徑及噴槍使用量可只能根據投資者訴求定制開發;
4. 才可以半自動的,又可自動的,噴砂口感好,一機經用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆適于面積 Applicable scope
適合于不少小產品的手工或自行噴砂,舉列:電竹木品、螺釘、塑料制
品、鈕扣、衣服拉鏈、壓克力板、刷卡機零配件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
