噴砂（丸）房系列的新產品

船舶制造分階段噴涂房-船泊特涂系統

Ship section coating room-special ship coating equipment

1、整套直接性噴漆基礎施工標準規范；基本原則是保障海洋工作環境工作環境；每次、分批操作Sa2.5級；一個衡量表層總體目標實用生存期15年工程施工工藝。

2、（邊部園角）2mm；涂膜弄壞高于2%或25m2,噴砂外理Sa2.5級。

3、（粗造度）30-75um；外壁室溫比露點高3℃；干膜板厚為320um。

4、（粉末大大小小）3、4、5臟污分布點1級；眼睛由此可見更小粉塵的還原。

5、（氯化鈉）50mg/m2；500總噸船用海艙；150m長散貨船雙舷側。

6、噴涂工藝水平尺寸規格書6三要素：產品的名號、金屬涂層材質、建筑施工策略、膜厚的范圍、前解決、周圍環境。

7、70%Sa2級（檢測不是很完成底漆）；完成底漆掃砂或超高壓水的洗滌。

8、（相對于溫度）不低于85%。

9、90/10方式：90%可達到標準規范值，10%高達條件值的90%。

1.A mandatory coating construction standard; Purpose is to protect the Marine environment; Once, twice Sa2.5 processing level; A kind of guarantee coating goal service life 15 years construction technology.

2.(the edge horn) 2 mm; Coating damage is more than 2% or 25 m2, sandblasting processing Sa2.5 level.

3.(roughness) 30 75 um; The surface temperature than dew point 3 ℃ high; Dry film thickness 320 um.

4.(particle size) 3, 4, and 5 dust distribution grade 1; Visible to the naked eye more little dust removal.

5.(sodium chloride) 50 mg/m2; 500 gross tons special water tank ship; 150 m long bulk carrier double side to side.

6.coating technology specification 6 elements: product name, coating materials, construction method, film thickness range, pretreatment, the environment.

7.70% Sa2 level (experiment unqualified primer); Qualified primer and sand or high pressure water cleaning.

8.(relative humidity) less than 85%.

9.90/10 rule: 90% to 10% of the value standard of 90%.

表明規定標準要求，我們的的精準服務機率有此類：

1、當我們能否我認為僅有涂漆房不一些 能做到PSPC實驗室管理標準，是都沒有噴涂工藝房更不能夠能夠滿足實驗室管理標準；以至于是都沒有噴涂工藝房的.我都也可幫到基礎建設，有噴涂工藝房的.我都也可幫到建立健全。

2、15年運用人類壽命的標準，或者對另一個產業有參考用處。

3、生態環境我門就可以做好無弄臟。

4、Sa2.5級一味著更高效噴砂和收集軟件的用和緩解。

5、變厚度把握意思著磨料磨具轉移設備的想要挺高了（另存細小粒，洗去灰塵）。

6、氣溫、空氣濕度、重量論文檢測實驗儀器使用的率大大大幅提高自己。

7、含鹽量、除污度、塵土檢測工具大批量采購計劃。

8、表面層吸塵器原理機（直流電動、手動、防爆設備）大批動用。

9、噴涂房燈飾建筑設施概率需改變，考慮燈具開關、設計制作設計、配置建筑。

10、為保護環鏡要求標準：節省的收塵程序、高效的電加熱程序、正規的去濕程序變成 防腐蝕涂料進行施工必須要機器設備。

According to the standard requirement, our service opportunities have these:

1.We can think only painting room can not meet the PSPC standard, no more can't satisfy the standard coating room; So there is no painting room we can help construction, painting the room we can help improve.

2.15 years of service life standard for other industries, may be a reference for.

3. we can do no pollution environment.

4.Sa2.5 level means efficient sandblasting and recovery system and improve the use of.

5.Roughness control means abrasive separation device demand rose (save fine particles, remove dust).

6.Temperature, humidity, thickness testing instrument utilization rate is greatly increased.

7.And salinity, cleanness and dust detection in large quantities.

8.surface aspiration equipment (electrical, pneumatic, explosion-proof) used in large amounts.

9.Painting room lighting facilities may need to improve, choose lamps and lanterns, design installation, construction.

10.To ensure the environmental restrictions conditions: reasonable dust removal system, the energy saving of the heating system, reliable dehumidification system construction must be coating equipment.

對待漁業修造市場IMO鋁層使用性能標準(PSPC)的實施，斯特爾機械提供船舶噴砂涂裝設備系統整體解決方案及技術支持，為船舶修造行業設計制造完善的船舶分段噴砂房噴漆房，鋼板拋丸預處理線，舾裝件、艙口蓋等船體部件二次分段涂裝房，壓載艙特涂設備，連續高效噴砂設備及回砂系統設備，精準的砂塵分離裝置，環保節能型除塵設備，大中型真空吸砂設備，組合式除濕機，高效暖風機，移動防爆風機，電動/自動/隔爆型型吸塵器原理機械，高壓低壓水拆洗機械，室溫、水分子含量、機的薄厚在線判斷分析儀器，含鹽量、清潔衛生度、塵埃用在線判斷機械。

Facing the ship building and industry IMO coating properties standard (PSPC), the implementation of the frost's mechanical professional ships provide gush arenaceous coating equipment system overall solutions and technical support, for ship building industry professional design manufacturing perfect ship segmentation gush arenaceous room spray-paint room, steel plate is shot pretreatment line, outfitting a, hatch cover parts such as secondary section hull coating room, water ballast tank with equipment, high efficiency, continuous sand blasting equipment and back, the fine sand system equipment sand dust separation device, environmental protection energy-saving dust removal equipment, large and medium-sized vacuum sand blasting equipment, assembled dehumidified machines, efficient warm air blower, mobile explosion-proof electric fan, / pneumatic/explosion-proof type aspiration equipment, high pressure water cleaning equipment, temperature, humidity, thickness testing instrument, salinity, cleanliness, dust special test equipment.
